Product Details
- Place of Origin: Hunan
- Brand Name: nongyou
- Model Number: 1GZ-180
The company does not forget its social mission while developing, actively participates in public welfare undertakings, donated nearly RMB 3 million in recent years, and won the honorary title of "advanced enterprise in tax paying at Shuangfeng County" for four consecutive years. The legal representative Liu Ruoqiao (Tel. 15773879999) who won the "Hunan Charity Award" is a member of the National Agricultural Standardization Technical Committee, and provincial outstanding entrepreneur.
- Place of Origin: Hunan
- Brand Name: nongyou
- Model Number: 1GZ-180
| name | parameter | Remarks |
| Equipped with power | 5.0KW | Optional power |
| Dimensions（cm) | 180*120*110 | Length * width * height |
| Machine quality（kg） | 140 | Containing diesel engine |
| Work efficiency（hm²/h） | ≥0.075 | ≥ 1.2 mu / h |
| Working width（cm) | 110 | |
| Maximum track（cm） | 94 | |
| Minimum turning radius（cm) | ≤160 | |
| Total number of installed handle (handle) | 24 | |
| The stall speed (kw / h) | Ⅰ - 3.5 | |
| Ⅱ - 4.5 | ||
| Transmission structure | form | Front - wheel drive rear - wheel drive |
| Power output shaft | Stand-alone, rotary spindle speed 335r / min | |
| engine | 180 diesel engine, see the diesel engine manual | |
| diesel engine | Calibration speed 2600r / min | |
| clutch | Three-piece, single-acting, dry type often combined with friction | |
| Tillage performance | Fuel consumption（L/hm²） | ≤12 (0.7 l / mu) |
| Farming wide（cm） | 90 | |
| Deep tillage（cm） | ≥10 | |
| Crushing rate（%） | ≥50.0 | |
| Scope of application | Widely used in hills, mountain mud feet ≤ 300mm, width ≥ 3000mm paddy fields, dry land | |
